Siemens 1LA9 25HP 3550RPM TEFC Motor 460V 3PH 1.15SF Premium Efficiency IP55

ZOMBIE COMPONENTS

Siemens 1LA9 25HP 3550RPM TEFC Motor 460V 3PH 1.15SF Premium Efficiency IP55

Siemens 1LA9 25HP 3550RPM 3PH TEFC Motor 460V 1.15SF IP55 Premium Efficiency
This listing is for a brand new Siemens 1LA9 Series 25HP 3-phase induction motor, built for industrial-grade continuous duty applications. Manufactured in Germany, this motor is designed to meet NEMA Premium Efficiency standards and provide outstanding durability and reliability in demanding environments.
It features a TEFC (Totally Enclosed Fan Cooled) enclosure with IP55 protection, making it ideal for both indoor and outdoor use where dust and water resistance are required. The high-speed 3550 RPM design makes it perfect for pumps, compressors, and other high-inertia loads requiring robust performance.
🔧 Specifications:
AttributeDetails
Manufacturer
Siemens

Model
1LA91662KA60-Z

Rated Output
25 HP / 18.5 kW

Voltage
460V (Delta)

Current
28.0 A

Frequency
60 Hz (50/60Hz capable)

Base Speed
3550 RPM

Enclosure Type
TEFC (Totally Enclosed Fan Cooled)

Frame Type
IEC Frame (160M or 160L typical for this model)

Efficiency
91.0% (NEMA Premium Efficiency)

Power Factor
0.92

Service Factor
1.15

Insulation Class
Class F

Protection Class
IP55

Design Letter
NEMA Design A

Duty Rating
Continuous (S1)

Country of Manufacture
Germany

✅ Features:
High-efficiency motor for energy savings and lower operating costs

Fully enclosed, fan-cooled (TEFC) design for rugged industrial environments

Premium insulation and winding construction for inverter (VFD) compatibility

Dust-protected and water jet resistant (IP55)

Built to last – Siemens industrial quality

LOCAL PICKUP OR FREIGHT – BUYERS CHOICE. WE WILL PACKAGE ON PALLET FOR CARRIER OF YOUR CHOOSING

WE SHIP WORLD WIDE!

ACTUAL RATED INPUT VOLTAGE	460 V
INVERTER/VECTOR DUTY RATING	Inverter Duty Capable
SPECIAL MOTOR CONSTRUCTION	Premium Efficiency (NEMA Premium)
BASE RPM	3550
MPN	1LA91662KA60-Z
INSULATION CLASS	F (Max 311°F)
CURRENT TYPE	AC
SERVICE FACTOR	1.15
NEMA FRAME SUFFIX	Not Applicable
RATED/FULL-LOAD TORQUE	37 lb-ft
FULL LOAD AMPS	28 A
RATED LOAD (HP)	25
IEC FRAME SIZE	160M
NEMA DESIGN LETTER	A
AC FREQUENCY RATING	50/60 Hz
ENCLOSURE TYPE	TEFC (Totally Enclosed Fan Cooled)
SHAFT TYPE	Keyed
AC MOTOR TYPE	Induction/Asynchronous
SHAFT DIAMETER	42 mm
MOUNTING TYPE	Foot-Mounted
Brand	Siemens
REVERSIBLE/NON-REVERSIBLE	Reversible
PROTECTION AGAINST LIQUIDS	Water Jets (6.3mm nozzle, 30kPa)
IP RATING	IP55
NOMINAL RATED INPUT VOLTAGE	460 V
MODEL	1LA9
AC PHASE	Three Phase
COUNTRY/REGION OF MANUFACTURE	Germany
Condition	New – Open box
Condition Description	*** 60 DAY MONEY BACK GUARANTEE ***
PROTECTION AGAINST SOLIDS	Dust Protected
