Panasonic Sanyo MDF-U76VC-PA VIP Plus -86C ULT Freezer 25.7 Cu Ft

Panasonic / Sanyo MDF-U76VC-PA Ultra-Low Temperature Upright Freezer

This listing is for a Panasonic / Sanyo MDF-U76VC-PA ultra-low temperature laboratory freezer. This is a large-capacity upright ULT freezer designed for biological sample storage, pharmaceutical storage, biotech, medical, clinical, university, and research laboratory applications.

Manufacturer documentation for the MDF-U76VC lists this unit as a 728 L / 25.7 cu ft ultra-low temperature freezer with a stated cooling performance of -86°C at the center of the chamber under no-load test conditions. The temperature control range is listed as -50°C to -86°C, with AC 220V, 60 Hz power and rated power consumption of 980 W.

Key Specifications

• Manufacturer: Panasonic / Sanyo
• Model: MDF-U76VC-PA
• Type: Upright ultra-low temperature freezer
• Temperature control range: -50°C to -86°C
• Capacity: 728 L / approximately 25.7 cu ft
• Power: AC 220V, 60 Hz
• Rated power consumption: 980 W
• External dimensions: 1010 mm W x 870 mm D x 1990 mm H
• Internal dimensions: 870 mm W x 600 mm D x 1400 mm H
• Shelves: 3 adjustable stainless steel shelves
• Inner doors: 2 insulated inner doors
• Approximate weight: 365 kg / approximately 805 lb
• Refrigeration: Cascade system
• Refrigerants: R-404A high stage / R-508B low stage
• Insulation: Vacuum insulation panel plus rigid polyurethane foam
• Alarm functions: High temperature, low temperature, power failure, door alarm, filter alarm
• Remote alarm contact: Equipped

The manual lists the MDF-U76VC with 728 L capacity, painted steel interior/exterior, stainless adjustable shelves, two insulated inner doors, cascade refrigeration, Pt1000 temperature sensor, multiple alarm functions, and a built-in voltage booster for the VC version.

Condition

Used unit in working condition. Unit has been tested to -86°C. Cosmetic wear, scuffs, scratches, sticker residue, or other signs of normal laboratory / industrial use may be present. Please review photos carefully for exact condition.

Included

• Panasonic / Sanyo MDF-U76VC-PA ultra-low freezer
• Installed shelves shown in photos
• Keys, racks, recorder, backup system, cables, or other accessories included only if shown or specifically stated

Important Electrical Note

This is a 220V ultra-low laboratory freezer. Buyer is responsible for verifying electrical compatibility and installation requirements before purchase. Unit may require a dedicated circuit.

Shipping

Freight shipping required due to size and weight. Buyer to arrange pickup or freight. We can assist with packaging and load onto carrier of your choice.
