KOLLMORGEN GOLDLINE DDR DIRECT DRIVE ROTARY SERVO MOTOR D141M-12-9327-001

ZOMBIE COMPONENTS

KOLLMORGEN GOLDLINE DDR DIRECT DRIVE ROTARY SERVO MOTOR D141M-12-9327-001

Kollmorgen Goldline DDR D141M-12-9327-001:
Outer Diameter: 361.9 mm (14.25 inches)
Peak Torque: 367 Nm (271 lb-ft)
Continuous Torque: 108 Nm (80 lb-ft)
Maximum Operating Speed: 200 RPM (3.3 RPS)
Peak Current: 72.5 A
Continuous Current: 21.5 A
Voltage Rating: 230 VAC (3-phase)
Rotor Inertia: 0.120 lb-ft·s² (0.163 kg·m²)
Encoder Resolution: 1,048,576 counts/rev
Repeatability: ±1.24 arc-sec
System Accuracy: ±27 arc-sec
Maximum Axial Load: 12,700 lbf (5,760 kgf)
Static Friction: 3.5 Nm (2.6 lb-ft)
Weight: 59.4 kg (131 lbs)
BUYER TO ARRANGE FREIGHT SHIPPING, WE WILL PALLETIZE AND LOAD ON THE CARRIER OF YOUR CHOICE WITH OUR FORKLIFT

WE SHIP WORLD WIDE!
