Original price was: £369.58.Current price is: £295.67.

Used Lenze Series 8200 Vector Inverter Drive E82EV302-4C With Profibus E82ZAFPC010 60 DAY MONEY BACK GUARANTEE

Out of stock

SKU: 126976017088_771E Category:
Description
ZOMBIE COMPONENTS
Lenze Series 8200 Vector Inverter Drive E82EV302-4C With Profibus E82ZAFPC010

Lenze Series 8200 Vector Inverter Drive E82EV302-4C With Profibus E82ZAFPC010

Lenze 8200 Vector Inverter Drive E82EV302-4C
  • Power Rating: 3 kW
  • Input Voltage: Three-phase 400/500 VAC, 50/60 Hz
  • Output Voltage: 0–100% of supply voltage
  • Output Current: 7.2 A (at 400 V) / 9.5 A (at 500 V)
  • Control Type: Vector control with or without speed sensor
  • Switching Frequency: Adjustable (4 kHz default, up to 16 kHz with derating)
  • Overload Capacity: 150% for 60 seconds, 200% for 3 seconds
  • Braking Chopper: Integrated
  • Protection Class: IP20
  • Cooling Method: Forced ventilation with internal fan
  • Dimensions (H x W x D): Approximately 320 mm x 125 mm x 175 mm
  • Weight: ~5 kg
Profibus Module E82ZAFPC010
  • Communication Protocol: PROFIBUS-DP
  • Baud Rate: Up to 12 Mbit/s
  • Connection Type: 9-pin Sub-D connector
  • Supported Functions: Cyclic and acyclic communication, parameter access via DP-V1
  • Configuration: Supports GSD file-based setup
  • Diagnostic Capabilities: Status and fault monitoring via PROFIBUS
  • Mounting: Plug-in module for 8200 Vector series

WE SHIP WORLD WIDE!

  • Power Rating: 3 kW
  • Input Voltage: Three-phase 400/500 VAC, 50/60 Hz
  • Output Voltage: 0–100% of supply voltage
  • Output Current: 7.2 A (at 400 V) / 9.5 A (at 500 V)
  • Control Type: Vector control with or without speed sensor
  • Switching Frequency: Adjustable (4 kHz default, up to 16 kHz with derating)
  • Overload Capacity: 150% for 60 seconds, 200% for 3 seconds
  • Braking Chopper: Integrated
  • Protection Class: IP20
  • Cooling Method: Forced ventilation with internal fan
  • Dimensions (H x W x D): Approximately 320 mm x 125 mm x 175 mm
  • Weight: ~5 kg
Profibus Module E82ZAFPC010
  • Communication Protocol: PROFIBUS-DP
  • Baud Rate: Up to 12 Mbit/s
  • Connection Type: 9-pin Sub-D connector
  • Supported Functions: Cyclic and acyclic communication, parameter access via DP-V1
  • Configuration: Supports GSD file-based setup
  • Diagnostic Capabilities: Status and fault monitoring via PROFIBUS
  • Mounting: Plug-in module for 8200 Vector series
Additional information
Weight 3.62873896 lbs
Dimensions 14.00 × 8.00 × 8.00 in
Brand

MODEL

Vector 8200
MPN

Condition

Condition Description
